Thomas C.: Fit with a small cut of the larger block
United States on Jul 08, 2023
planb: It did fit and no cutting(which might be where people that have to cut are running into problems) You cant cut the lip off so you have to cut the ends which have 2 separate cuts because the shape of the firebox(its not square) No instructions. The only Y/T video that shows how to do it ,dose not work on the 8570.It does matter which piece goes where.(It might very for each stove)Otherwise you will have a gap like some reviews described.The larger piece goes on theR with the lip facing down.The smaller goes on the L with lip up.Video says to slide between the 1st & 2nd tube,,NO,not mine.It slides up in front of the first tube and the the baffle support(#33 on the parts diagram) the baffle support just lays up there. Another tip is make sure you remove all the old crap from the back where the baffle rest.If everything does not line up and gap is not tight there might be something still in there.And there is NO cotter pins holding the baffle on the 8570.The back of the baffle nestles in,and the baffle support holds it in place .
United States on Feb 04, 2023
Ryan: Product looks great, well packaged and arrived in a timely fashion; for some reason even with ordering the correct model replacement for my hearthstone I had to drill for the brackets and assemble the Humpty Dumpty broken pieces of my old one and re-cut this entire board to fit the stove, not the most difficult job ever but these extra steps didn’t help save any time
Canada on Nov 13, 2022
Polli4770: This replacement baffle board for our Hearthstone Clydesdale insert was very economical when compared to a factory original which runs in the neighborhood of $200+. The most difficult part of replacing this board is the removal of the board carrier frame which is quite heavy and somewhat time consuming and difficult to do. You can go to Hearthstone's web site and see the procedure in the page for the Clydrsdale insert. Be very careful how you handle this board as it is very light and fragile. I would suggest that you apply some anti seize to the screws and bolts to make them easier to remove in the future. Since the original board was about six years old, I can't rate how long this board may last. Although this board was received in good condition thanks to its factory packaging, Amazon did a poor job by placing it in an oversized carton with no paper or peanuts to keep it from sliding around.
United States on Nov 09, 2022
Jj: I originally was disappointed in this product due to it cracking on 2 units so I wrote to linn mfg. and could not be more impressed with the timely response to me and their genuine interest in the problem. Their response
In short, yes we will certainly replace it. Below is a bit more information on this particular board - as we have made a change to the design to help with the issue you have had.
I apologize for experience you've had with the product. Regarding this particular item, we have actually made a recent change in the design of the board, as we believe part of the cracking to be due in part to the method the board is fastened to the heat tubes with the pins. The high-temperature insulation of the baffle boards actually shrinks as it heats up, where the metal expands, thus creating a lot of stress on the board as it is pinned to the tubes. Nearly all of the failures we have seen end up going through the mounting holes which has led us to believe this is the main cause. We rarely change the design from what the OEM uses, but in this case we believe a change is needed. In the latest version of the board, we have changed the holes to be elongated slots so there is...
United States on Mar 05, 2021
RENE: Très bon produit et sécuritaire pour le poêle à bois
Canada on Nov 24, 2020
Amazon Customer: well packaged, straight forward installation. replaces a hearthstone heritage baffle board without issues.
Canada on Feb 18, 2019
| Lynn Manufacturing Hearthstone Baffle Board Replacement Kit | Replacement Gasket Kit for Woodburning Stoves by Midwest Hearth | QuadraFire 3-Speed Blower Control Box for Fireplaces | |
|---|---|---|---|
|
 |
 |
|
| B2B Rating |
85
|
97
|
95
|
| Sale off | |||
| Total Reviews | 33 reviews | 182 reviews | 17 reviews |
| Batteries required | No | No | No |
| Item Weight | 3.79 pounds | 8.1 ounces | 1 pounds |
| Package Dimensions | 22.5 x 13.25 x 1.75 inches | 7.6 x 4.76 x 2.28 inches | |
| Is Discontinued By Manufacturer | No | No | No |
| Import | Made in US | ||
| Item model number | 2425A | MH-KIT | SRV7000-704 |
| ASIN | B071YX2W21 | B01D0ORS48 | B00LNF53YY |
| Best Sellers Rank | #107,378 in Home & Kitchen #27 in Fireplace Replacement Parts | #6,718 in Home & Kitchen #1 in Fireplace Replacement Parts | #294,716 in Home & Kitchen #24 in Space Heater Replacement Parts |
| Customer Reviews | 4.6/5 stars of 318 ratings | 4.6/5 stars of 3,840 ratings | 4.6/5 stars of 153 ratings |
| Manufacturer | Lynn Manufacturing | No | No |
United States on Oct 08, 2023
